This VAN DE STADT SAMOA 47 is sold. you may also like:
(108)
VAN DE STADT SAMOA 47
- Dimensions
- 14.60 x 4.50 x 2.40 (m)
- Material
- Aluminium
- Built
- 2005
- Engine(s)
- 1x Volvo Penta TMD22 diesel
- HP/ KW
- 1x 77.00(hp), 56.60(kw)
- Lying
- at sales office
- Sales office
- De Valk Sint Annaland
- Status
- Sold
Broker's comments
This custom Samoa 47 has been optimised and restyled by Van de Stadt Design for better performance, short handed sailing, cruising comfort and safety. She is full of practical but also beautiful details and equipped for fast long distance cruising. With just the owners couple or with guests onboard. Looking for a yacht perfect for a successfull ARC Rally? Come onboard and realise your plans.
De Valk Sint Annaland
+31 166 601 000
Photos (108)
Download brochure
Share this yacht
Specifications: VAN DE STADT SAMOA 47
General
- Model VAN DE STADT SAMOA 47
- Type sailing yacht
- LOA (m) 14,60
- LWL (m) 12,00
- Beam (m) 4,50
- Draft (m) 2,40
- Air draft (m) 23,20
- Headroom (m) 1,92
- Year built 2005
- Builder RT Yachtbau
- Country Slovenia
- Designer Vd Stadt & Partners
- Displacement (t) 14,6
- Ballast (tonnes) lead in aluminum 5,8
- CE norm A
- Hull material aluminium
- Hull colour blue
- Hull thickness (mm) in stronger Alustar 6-7 mm
- Hull shape round-bilged
- Keel type fin keel with bulb
- Superstructure material aluminium
- Rubbing strake aluminum
- Deck material aluminium
- Deck finish teak
- Superstructure deck finish teak
- Cockpit deck finish teak
- Dorades stainless steel 6 x
- Window frame aluminium
- Window material polycarbonate
- Deckhatch flush mounted
- Portholes aluminium
- Insulation foam plates
- Fuel tank (litre) aluminium 2 x 350
- Level indicator (fuel tank) yes
- Fuel daytank (litre) stainless steel 100
- Level indicator (daytank) yes
- Freshwater tank (litre) aluminium 500 + 100
- Level indicator (freshwater) yes
- Blackwater tank (litre) polyethylene 270
- Level indicator (blackwater) yes
- Blackwater tank extraction deck extraction + uw line
- Greywater tank (litre) aluminium 500
- Level indicator (greywater) yes
- Wheel steering rack & pinion 2 x Whitlock
- Emergency tiller yes
- Extra info The standard Van de Stadt 47 Samoa design and constuction has been optimised to get the best possible performance and handling from this already excellent design from the Van de Stadt design team. Built in high grade Alustar aluminium (20% stronger and lighter than standard AIMg4)
- Cabins 3
- Berths 6
- Interior cherry
- Floor wood
- Saloon yes
- Headroom saloon (m) 1,92
- Heating central hot water Eberspaecher Hydronic 10
- Chart table yes
- Aft Cabin 2 x
- Dinette yes
- Galley yes
- Countertop plastic
- Sink stainless steel
- Cooker calor gas Force 10 (2017)
- Oven Force 10
- Fridge Privileg (24v)
- Freezer Privileg (220v)
- Hot water system 220V + engine
- Water pressure system electrical Rheinstrom
- Owners cabin double bed
- Bed length (m) 2,00 x 1,50
- Wardrobe hanging and shelves
- Bathroom en suite I
- Toilet en suite
- Toilet system electric Tecma
- Wash basin in the bathroom
- Shower en suite
- Extra info 220v sockets in all cabins
- Guest cabin 1 double bed
- Bed length (m) 2,00 x 1,20
- Wardrobe hanging and shelves
- Bathroom shared II
- Toilet shared
- Toilet system electric Tecma
- Wash basin in the bathroom
- Shower yes
- Guest cabin 2 double bed
- Bed length (m) 2,00 x 1,20
- Wardrobe hanging and shelves
- Washing machine 220v Candy Euronova 600
- Extra info LED lighting (2017)
- Extra info 220v Stove is also available for installing
- No of engines 1
- Make Volvo Penta
- Type TMD22
- HP 77,00
- kW 56,60
- Fuel diesel
- Year installed 2004
- Maximum speed (kn) 8
- Cruising speed (kn) 6
- Consumption (l/hr) 3,5
- Engine hours 1500
- Engine cooling system freshwater heat exchanger
- Drive shaft
- Shaft seal yes
- Engine controls bowden cable
- Gearbox Volvo HS25A
- Bowthruster electric Maxpower VP150 retractable (2018)
- Exhaust watercooled
- Thrust bearing yes
- Propeller type folding SPW
- Propeller blades 3
- Propeller shaft material stainless steel
- Shaft lubrication water
- Electric bilge pump 4 x
- Electrical installation 12/24/220v
- Generator Fisher Panda AGT 4000
- Running hours generator 347
- Start battery 1 x 90ah (2018)
- Service battery + 12v 240ah (2018) 24v 500ah (2014)
- Generator battery 1 x
- Battery monitor 2 x Victron
- Battery charger Victron 12v/25amp
- Battery charger/inverter 24v/3000watt/70amp Victron Multiplus
- Diode battery combiners yes
- Shorepower with cable
- Insulation transformer Victron 3600
- Watermaker (not in operation) Schenker
- Extra info Truma electric gas-shut-of valve
- Extra info mass-short indicator
- Extra info Most of the electronic installation has been rebuilt and overhauled in 2017-2018.
- Compass Silva
- Electric compass all NMEA2000 intergrated Furuno FI70 (2017)
- Depth sounder Furuno FI70 (2017)
- Log Furuno FI70 (2017)
- Windset Furuno FI70 (2017)
- VHF Furuno 400
- Autopilot + extra unit inside Furuno Navpilot 511
- Wind vane steering install. Windpilot
- Rudder angle indicator via autopilot
- Radar Furuno Impuls (2017)
- GPS Furruno GP-32
- Plotter 17+9 inch screens 2 x
- Personal computer + Time Zero software Marine PC + internet (2017)
- AIS transponder Seapilot Class B (2017)
- Navigation lights LED lighting
- Sprayhood (2017)
- Cockpit table yes
- Bathing platform yes
- Boarding ladder stainless steel
- Deck shower hot + cold
- Anchor CQR Plough Stainless steel
- Anchor chain 70 mtrs Stainless steel
- Windlass electrical Lewmar
- Capstan Lewmar
- Dinghy inflatable Zodiac
- Outboard 4-stroke Mercury 6hp
- Outboard support yes
- Sea railing wire
- Grab rail (superstructure) stainless steel
- Railing side opening gates 2 x
- Pushpit yes
- Pulpit yes
- Life raft container Zodiac (2016)
- Life raft (pers) 6
- Last life raft survey 2016
- Lifejackets yes
- Lifebuoy 2 x
- Safety lines on deck yes
- Fenders yes
- Mooring lines yes
- Fire extinguisher 2 x
- Rigging fractional
- Standing rigging Rod
- Brand mast High peformance Nordic
- Material mast aluminium coated
- Spreaders with diamond spreader 3 x
- Keel stepped mast yes
- Battcars rollerbeared Harken
- Fully battened mainsail Quantum Sails (2018)
- Genoa Quantum Sails (2018)
- Genoa I North 3Di (2014)
- Genoa furler drum below decks Harken
- Code Zero with furler North Sails
- Gennaker North Sails
- Stormjib yes
- Reefing System slabreefing
- Backstay adjuster hydraulic Navtec
- Boomvang hydraulic Navtec
- Primary sheet winch electric 2 x Harken 56ST
- Secondary sheet winch 2 x Harken 56ST
- Halyard winches electric 1 x Harken 47ST
- Multifunctional winches 1 x Harken 47ST
- Spi-pole aluminium Sparcraft
- Extra info hydraulic outhaul Park Ave boom Navtec
- Extra info The decklayout is very pratical and copied from the Swan 53 for optimum performance and ease of handling.
Important disclaimer:These particulars are given in good faith as supplied but cannot be guaranteed and cannot be used for contracts.
